Air Conditioner

DEAKONET ® EU Registered Trademark

Inverter Air Conditioners Product Catalogue 2026

Residential Split Systems · 9K–28K BTU · Comfort Engineered for Lower Energy Use

❄️ 9K–28K BTU

⚡ SEER up to 6.6

🌡️ SCOP up to 4.4

🔇 From 25 dB(A)

📱 APP Control

🏭 30,000 m²Modern Facility

📦 200,000Annual Capacity

🌍 50+Export Markets

🔬 5%Revenue in R&D

❄️ -45°CTest Lab

DEAKONET inverter air conditioners deliver precise temperature control with lower energy consumption. Designed for residential spaces, the split-system platform offers cooling, heating, and smart connectivity across five capacity classes from 9,000 to 28,000 BTU.

Inverter Technology

Compressor speed adjusts in real time instead of repeatedly switching fully on and off. Precise modulation supports stable room temperature, quieter starts, and lower running cost.

Capacity Range

9,000 BTU 12,000 BTU 18,000 BTU 24,000 BTU 28,000 BTU

9–12K BTU
Typical room: 15–24 m²

18K BTU
Typical room: 24–36 m²

24K BTU
Typical room: 32–48 m²

Technical Specifications

Specification	SAS09B	SAS12B	SAS18B	SAS24B	SAS28B
Cooling Capacity (BTU)	9,000	12,000	18,000	24,000	28,000
Heating Capacity (BTU)	9,400	12,600	18,000	24,000	28,000
Cooling Input (W)	800	1,300	1,700	2,000	2,700
SEER	6.1	6.1	6.1	6.6	6.3
SCOP	4.0	4.0	4.0	4.0	4.4
Indoor Noise (min.)	25 dB(A)	30 dB(A)	34 dB(A)	35 dB(A)	35 dB(A)
20 ft GP Loading	112	112	90	56	47

Dimensions & Weight

Component	Dimensions (W × H × D)	Net Weight
Indoor Unit – 9–12K BTU	821 × 283 × 200 mm	9–9.5 kg
Indoor Unit – 18K BTU	1,003 × 310 × 222 mm	13.5 kg
Indoor Unit – 24–28K BTU	1,109 × 331 × 250 mm	16.5 kg
Outdoor Unit – 9–12K BTU	830 × 540 × 325 mm	23–23.5 kg
Outdoor Unit – 18K BTU	890 × 598 × 372 mm	33 kg
Outdoor Unit – 24K BTU	960 × 700 × 396 mm	42.5 kg
Outdoor Unit – 28K BTU	990 × 790 × 426 mm	51 kg

Operating Modes

🌿 ECO Mode

Fine-tunes output to maintain comfort with lower running cost.

⚡ Turbo Cooling

Maximizes output at start-up for rapid temperature pull-down.

🌙 Sleep Mode

Optimizes temperature and fan speed automatically overnight.

🔄 Auto Restart

Restores previous operating settings after a power interruption.

PV-Ready Architectures

Architecture	Best Fit	System Components
PV Direct + Grid	Daytime cooling with reliable grid	PV strings · DC interface · AC backup
PV + Battery + Grid	Remote critical loads	PV · hybrid inverter · LFP battery · grid
PV + Battery, Off-Grid	Sites without utility supply	PV oversizing · LFP · genset option
AC-Coupled Retrofit	Existing PV/storage plants	Standard inverter AC + EMS signals

Smart Monitoring

Live System Overview — PV, grid, battery and load power at a glance
Operating Mode Display — Real-time mode shown clearly
Energy Yield Tracking — Daily, monthly and cumulative data
Power Flow Visualization — Visual direction for faster diagnosis
Mobile Access — Remote farm operations via app

Installation Requirements

📏 Piping Length

10–50 m max. per model

📐 Height Difference

5–25 m max. per model

🔌 Power Supply

220–240V · Single-phase · 50-60Hz

🔧 Connection

Flare connection · Professional installation required

🔒 10–12 Years — Compressor · Inverter PCB · Condenser
Warranty periods vary by region, brand and sales agreement. Confirm applicable terms at time of purchase.

OEM / ODM Services

Service	Details
Branding	OEM logo, model code, carton and manuals
Warranty	Target: 2 years complete unit / 5 years compressor
Lead Time	Sample: 7–15 days · Mass production: 15–20 days
Packaging	Export carton + foam · Pallet option · Moisture protection
Spare Parts	Recommended 1–2% service parts with first container
Documents	English manual · Wiring diagram · Parts list · QC record

Certifications

ISO9001

ISO45001

CCC

RoHS

SASO

About DEAKONET

DEAKONET is the EU-registered trademark of Foshan Juyang New Energy Co., Ltd., a National High-Tech Enterprise established in 2003 with over 20 years of HVAC R&D, production, and export experience. The company operates a 30,000 m² modern factory with extreme-climate test laboratory (-45°C validated), exporting to 50+ countries.

EU registration certificate No. 018791369 · Registered 21/02/2023

Foshan Juyang New Energy Co., Ltd.
No. 1, Hongke 2nd Road, Likou Industrial Zone, Honggang Village, Lishui Town, Nanhai District, Foshan, Guangdong 528244, China
T +86 757 8562 2139 E heatpump@dkren.com W www.heatpump-factory.com

Request a Quote →

* Specifications subject to change without prior notice as part of our ongoing product improvement program. For model selection, site assessment, and detailed OEM requirements, please contact the sales team.
