R32 Inverter Air Source Heat Pump

Name: R32 Inverter Air Source Heat Pump
Brand: FOSHAN JUYANG NEW ENERGY CO LTD
SKU: 6-45kW
Availability: InStock

Product Details

Place of Origin: China

Brand Name: DEAKONET

Certification: CE, ERP, UL

Model Number: 6-45kW

Payment & Shipping Terms

Minimum Order Quantity: 1

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:

Max. Outlet Water Temp.:	60°C	Min. Operating Ambient:	-30°C
Function:	Heating / Cooling / DHW	Wi-Fi APP Control:	Standard
4G Module (IoT):	Optional	Compressor:	Inverter
Condenser:	Plate Heat Exchanger	Water Pump:	Inverter (Optional Built-in)
Fan Motor:	DC (Standard)	Backup Heater:	3 / 6 / 9 KW (Optional Built-in)
Expansion Vessel:	Optional Built-in	PV Drive Module:	Optional Built-in

Max. Outlet Water Temp.:	60°C
Min. Operating Ambient:	-30°C
Function:	Heating / Cooling / DHW
Wi-Fi APP Control:	Standard
4G Module (IoT):	Optional
Compressor:	Inverter
Condenser:	Plate Heat Exchanger
Water Pump:	Inverter (Optional Built-in)
Fan Motor:	DC (Standard)
Backup Heater:	3 / 6 / 9 KW (Optional Built-in)
Expansion Vessel:	Optional Built-in
PV Drive Module:	Optional Built-in

Description

R32 Inverter Air Source Heat Pump

DEAKONET ® EU Registered Trademark

A3 PRO Series R32 Inverter Heat Pump

Heating · Cooling · Domestic Hot Water ｜ Monoblock Design ｜ 6–45 kW ｜ OEM/ODM Ready

🔌 230V / 380V 🌡️ Max Outlet 60°C 🔇 From 54 dB(A) 🌿 R32 · GWP 675 🏠 Residential & Light Commercial

Designed for the European market, the A3 PRO Series delivers high-efficiency heating, cooling, and domestic hot water in a compact monoblock package. With full DC inverter technology and intelligent controls, it offers stable comfort, quiet operation, and easy retrofit compatibility.

🔁 Auto-Changeover Automatically switches between heating, cooling, and DHW based on room and tank temperatures.

📱 Smart Control Wi-Fi APP control standard, with optional 4G IoT and Modbus/RS485 integration.

Key Features

Full DC Inverter — Compressor, fan, and pump continuously match load demand, reducing start-stop cycling and temperature fluctuation.
Weather-Compensated Control — Automatically adjusts target water temperature based on outdoor conditions.
Delta-T Pump Control — Inverter water pump adjusts flow to match real heating/cooling load.
Quiet Operation — Sound pressure as low as 54 dB(A), ideal for residential installations.
Hydrogen-Ready Design — Compatible with European heating terminals and DHW storage.
Premium Components — Inverter compressors with EVI, SWEP stainless steel plate heat exchangers.

Smart Control

📱 Wi-Fi / APP (Standard) 📶 4G IoT (Optional) 🔌 Modbus / RS485 (Optional) 🛋 Room Thermostat

Remote set-temperature adjustment, mode selection, and real-time monitoring.
Optional 4G modules with pre-installed SIM for plug-and-play monitoring without household WiFi.
IoT platform provides project overview, live operating data, alarms, and historical records.

Premium Components

Component	Specification	Customer Benefit
Compressor	Famous brand inverter rotary compressor with EVI	High efficiency, wide range, low vibration, strong low-temperature heating
Condenser	SWEP stainless steel R290/R32-compatible brazed plate heat exchanger	High heat transfer, compact footprint, corrosion resistance
Evaporator	Hydrophilic aluminum fin + inner-grooved copper tube	Improved heat absorption, frost resistance, anti-corrosion
Fan + Drive	Brushless DC fan motor + sine wave IPM drive	Quiet variable-speed airflow, smoother operation

Model Overview

230V Single-Phase Series

Model	A3 PRO-06	A3 PRO-09	A3 PRO-12	A3 PRO-15S	A3 PRO-18S
Rated Heating A7/W35 (kW)	6.0	9.0	10.5	15.0	18.0
Rated Heating COP	4.41	4.41	4.38	4.41	4.39
Rated Cooling (kW)	5.0	7.2	9.0	12.0	15.0
Cooling EER	2.84	2.83	2.83	2.81	2.83
SCOP @ 35°C	4.73	4.73	4.71	4.72	4.71
DHW Heating (kW)	7.5	12.0	13.5	18.0	22.5
Hot Water Output (L/h)	161	258	290	387	484

380V Three-Phase Series

Model	A3 PRO-15T	A3 PRO-18T	A3 PRO-22T	A3 PRO-30T	A3 PRO-45T
Rated Heating A7/W35 (kW)	15.0	18.0	22.0	30.0	45.0
Rated Heating COP	4.41	4.39	4.37	4.37	4.69
Rated Cooling (kW)	12.0	15.0	20.0	25.0	35.0
Cooling EER	2.81	2.83	2.84	2.84	2.78
SCOP @ 35°C	4.72	4.71	4.71	4.70	4.70
DHW Heating (kW)	18.0	22.5	30.0	37.5	50.0
Hot Water Output (L/h)	387	484	645	806	1075

Performance Data (A3 PRO Series)

Test conditions: EN14511 / EN14825 standards. Values shown are for model selection reference and require certified laboratory confirmation.

Model	A7/W35	A7/W55	A-7/W35	A-7/W55	A-15/W35	A-15/W55
A3 PRO-06	6.0 kW / COP 4.41	—	5.2 kW / COP 3.59	—	4.7 kW / COP 3.11	—
A3 PRO-09	9.0 kW / COP 4.41	—	7.7 kW / COP 3.59	—	7.0 kW / COP 3.11	—
A3 PRO-12	10.5 kW / COP 4.38	9.0 kW / COP 3.56	8.2 kW / COP 3.08	6.7 kW / COP 2.54	6.9 kW / COP 2.68	5.5 kW / COP 2.14
A3 PRO-15S/T	15.0 kW / COP 4.41	—	12.9 kW / COP 3.59	—	11.7 kW / COP 3.11	—
A3 PRO-18S/T	18.0 kW / COP 4.39	—	15.5 kW / COP 3.57	—	14.0 kW / COP 3.09	—
A3 PRO-22T	22.0 kW / COP 4.37	18.9 kW / COP 3.55	17.2 kW / COP 3.07	14.1 kW / COP 2.53	14.5 kW / COP 2.67	11.4 kW / COP 2.13
A3 PRO-30T	30.0 kW / COP 4.37	—	25.8 kW / COP 3.55	—	23.4 kW / COP 3.07	—
A3 PRO-45T	45.0 kW / COP 4.69	38.7 kW / COP 3.58	35.1 kW / COP 3.39	28.8 kW / COP 2.56	29.7 kW / COP 2.99	23.4 kW / COP 2.16

Full Technical Parameters

Parameter	A3 PRO-06	A3 PRO-09	A3 PRO-12	A3 PRO-15S	A3 PRO-18S	A3 PRO-15T	A3 PRO-18T	A3 PRO-22T	A3 PRO-30T	A3 PRO-45T
Power Supply	230V/1Ph		230V/1Ph		230V/1Ph	380V/3Ph
Rated Heating (kW)	6.0	9.0	10.5	15.0	18.0	15.0	18.0	22.0	30.0	45.0
Rated Heating COP	4.41	4.41	4.38	4.41	4.39	4.41	4.39	4.37	4.37	4.69
Rated Cooling (kW)	5.0	7.2	9.0	12.0	15.0	12.0	15.0	20.0	25.0	35.0
Cooling EER	2.84	2.83	2.83	2.81	2.83	2.81	2.83	2.84	2.84	2.78
Max Input Power (W)	2500	3500	4500	5500	6500	8500	8500	12500	12500	15500
R290 Charge (kg)	0.9	1.1	1.2	1.8	2.4	1.8	2.4	2.7	3.6	4.5
Noise dB(A)	54	54	54	55	56	55	56	56	57	59
Net Weight (kg)	85	85	95	115	125	115	125	140	185	200
Dimensions (mm)	1060×410×825			1080×420×1390				1280×480×1590
